R S S – the Reference Super Sub.

Time. The third and most important dimension of sound, is the main focus of the R S S. Only a genuine horn can produce it correctly and unlock the physical feel, emotion and definition of the original music signal. Hear and feel the difference to standard vented designs.

A 10 year R & D project with only one goal, to design the fastest and most accurate, best sounding subwoofer system possible today, without size or cost restrictions. Resulted in this unique, genuinely horn loaded 20kW subwoofer system comprised of a pack of four enclosures forming a perfect, actual 30Hz horn. Each enclosure is driven by a single very special 18” driver, with the fastest transient response, designed to perfectly drive and control this horn system.

This very large horn is divided into four easy to move and setup enclosures. Designed to be maximally space efficient in storage / transport and utilize the regular maximum height of doorways and cargo spaces, taking up only a small footprint in the warehouse. This also makes it possible to use the system upright in confined spaces to save valuable floor space.

Applications
In outdoor and large indoor, 2Pi applications, always used in packs of four enclosures (minimum), to achieve the perfect 30Hz reproduction, performance and directivity. In small indoor clubs, 4Pi applications, even packs of two enclosures, result in the best possible sounding bass reproduction.

Dispersion
Dependent on array setup and processing. A very large horn is always naturally directional.

Bandwidth
27Hz to 200Hz -3dB acoustic system response with 22Hz -10dB Low frequency cutoff.

Max SPL (combined system)
151dBpeak flat from 30Hz – 200Hz in half space (2Pi). Powered by 20kW dedicated processed amplifier power (5kW per cabinet).

Size / Weight
Width 1750mm
Depth 1080mm
Height 600mm
157kg per cabinet

In transport / storage position
Width 600mm
Depth 1080mm
Height 1875mm
(on attached castors)
